Aquamaster Bath Hoist

An ideal solution for carers to find the right lifting position and lower the users into the bath safely.

Aquamaster bath hoist

The Aquamaster fixed floor hoists feature an easy-to-clean white nylon coating. Carers can find the ideal lifting position easily as the seat rotates 360 degrees, locking every 90 degrees to ensure a safe transfer.

It is easy for caregivers to lower patients into the bath by using the winding handle. The hoist can be placed either at the side or end of the bath, depending on accessibility and preferences.

The Aquamaster bath hoist is available in both manual and electric versions. For manual versions, an electric conversion kit is available.

1 year warranty

N6212

  • Weight Capacity 130kg
  • Wooden or concrete floor fixings
  • Side or end fit configuration
  • Lap Belt
  • Detachable battery pack (electric version)
  • LCD battery level indicator (electric version)
  • Emergency lift and lower functions (electric version)
  • Optional safety harness for added security

Safe working load

130kg/20st/287lbs

Maximum height to base of seat

740mm

Minimum height to base of seat

140mm

Maximum seat travel

485mm

Maximum seat width

450mm

Maximum width between arms

395mm

Maximum seat depth

410mm

Centre of seat to centre of mast

430mm

Maximum seat turning radius

850mm

Maximum clearance from mast (to allow for seat rotation)

1000mm

Total weight (manual)

29kg

Total weight (electric)

37kg
