Technical Specification |
||
Standard Features | Options | |
Lift System | ||
Drive | Traction drive | Hydraulic drive |
Capacity | 255kg | – |
Rated speed | 0.08m/s | Fast motor – 0.15m/s (traction only) |
Cabin height | 1900mm | 1800mm or 2000mm |
Travel – traction drive | 4.2m | Extended travel up to 4.8m |
Travel – hydraulic drive option | 3.4m | n/a |
Rail guards | Transparent | – |
1st floor flix | Ceiling fix | Wall fix |
Emergency battery backup | Yes | – |
Cabin Features | ||
Lift colour | RAL 7035 | Custom colour |
Vision panels | 4mm acrylic | |
Rear side panels | RAL 7042 | |
flooring | Grey Anti-slip Vinyl | Marble or Oak effect vinyl, or custom |
LED lighting | White | Colour changing |
Door handrail | Yes | – |
Cabin handrail | No | Yes (RAL 7035), with or without controls |
Tip-up seat | No | 120kg Tip-up seat |
Custom finish | No | Price on request |
Operation | ||
Controls | Remote (radio) | Surface or flush (wired) |
Diagnostic display | 4 line LCD | 7″ colour LCD |
Door operation | Manual | Powered |
Emergency telephone | Yes | Autodialler |
Alarm | Yes | – |
